Jackson NXP-HTD High Temp Door Type Dishwasher w/ 58 Racks/hr Capacity, Built-in Booster, 208v/3ph

Product Details

• Door-type design
• Cleans 63 racks per hour
• Uses 56.1 gal. of water per hour
• 57-second cycle
• 20-in.-wide by 20-in.-deep racks
• Stainless steel construction
• Door-actuated start
• Top controls
• Built-in booster heater with Sani-Sure final rinse system
• Stainless steel nozzles
• Interchangeable upper and lower wash and rinse arms
• Delime cycle
• Stainless steel wash pump motor
• Protections for high temperatures and low water
• Automatic tank fill
• Vent fan control
• Detergent/rinse additive signal connection fuse box
• Scrap basket
• Adjustable bullet feet
• 17¹⁄₄-in. vertical chamber clearance
• Minimum rear wall clearance: 4 in.
• Minimum corner installation wall clearance: 4 in.
• Ideal minimum water operating temperature: 150 degrees F
• Ideal minimum rinse operating temperature: 180 degrees F
• Inlet water temperature: 110 degrees F

Product Features

*Free shipping on Jackson NXP-HTD within the 48 contiguous states.

Dimensions & Utilities

• 30⁵⁄₈ in. W x 29 in. D x 64 in. H
• 45.6 A, 10.5 kW, 1 HP
• 208 V/60 Hz/3 ph

From The Manufacturer

Dishwasher, door type, high temperature electric tank heat, built-in 70°F booster with Sani-Sure™, universal (straight-thru/corner) type, approximately (58) racks/hour capacity (0.89 gallons per rack), automatic tank fill, door-actuated start, digital temperature display, delime cycle, 17-1/4” vertical chamber clearance, interchangeable upper & lower wash/rinse arms, vent fan control, hi-limit thermostat, low water protection, detergent/rinse additive signal connection fuse box, 1 HP stainless steel wash pump motor, stainless steel exterior, adjustable bullet feet, cETLus, ETL-Sanitation, ENERGY STAR®

*Image may not depict product color, inclusions or accessories.

Specifications

Documents

• Spec Sheet
• Warranty
• Use & Care Guide
• Manual
• Installation Guide
• Brochure
• Catalog
