Hatco S-13 Imperial Booster Water Heater, 16 Gallon, 13 1/2 kW, 480v/3ph

Product Details

• Part of the Imperial series
• 16-gal. storage capacity
• Maximum 135 GPH at 40-degree-F rise
• Maximum 77 GPH at 70-degree-F rise
• High temperatures help flatware and dishes air-dry rapidly
• Thermostat can be lowered to 140 degrees F for low-temperature dish machines
• Conveniently accessible service area behind the front cover
• Castone-lined water tank is noncorrosive and nontoxic
• Temperature/pressure relief valve and pressure reduction valves prevent damage
• 2 gauges show the temperature and pressure levels
• High-temperature limit control for safety
• On/off switch
• Low-water cut-off keeps the heating elements from burning out
• Stainless steel front is durable and dent resistant
• Powder-coated, silver-gray hammertone finish
• Built-in heat trap and fiberglass insulation keep heat inside tank
• Heating elements are sheathed in metal for protection
• Pre-plumbed and pre-wired at the factory for operator convenience
• 6-in. legs

Dimensions & Utilities

• 28⁵³/₁₀₀ in. W x 22³/₄ in. D x 31³/₁₀₀ in. H
• 16.3 A, 13.5 kW
• 480 V/60 Hz/3 ph

*Free shipping on Hatco S-13 within the 48 contiguous states.

From The Manufacturer

Imperial Booster Heater, Electric, 16-gallon storage capacity, 13.5-KW, stainless steel front panel, powder-coated silver-gray hammertone body, 6" plastic non-leveling feet, Castone tank, NSF, cUL, UL, 480v/60/3ph

*Image may not depict product color, inclusions or accessories.

Specifications

Documents

• Spec Sheet
• Warranty
• Parts Breakdown
• Manual
• Brochure
