Ecoline by Hobart EUL-1 Low Temp Rack Undercounter Dishwasher w/ 24 Racks/hr Capacity, 120v

Product Details

• Sanitizes maximum of 24 racks per hour
• 5³⁄₁₀-gal. wash tank
• Chemical sanitization
• Undercounter unit
• 2-minute cycle time
• Uses ²³⁄₂₅ gal. of water per rack (22¹⁄₁₀ gal. per hour)
• Electric heating unit
• Soft start
• Snap-in revolving upper and lower anti-clogging wash and rinse arm
• Removable 3-part stainless steel scrap screen
• Automatic pumped drain
• Automatic fill
• Delime cycle
• User interface with digital temperature display
• Service diagnostics with error notifications
• Minimum wash and rinse operating temperature: 120 degrees F
• Minimum recommended building flowing water pressure: 20 PSI
• Recommended water hardness: 3 grains or less
• Peak drain flow rate: 2⁴⁄₅ GPM

Product Features

*Free shipping on Ecoline by Hobart EUL-1 within the 48 contiguous states.

Dimensions & Utilities

• Flat rack: 20 in. W x 20 in. D
• Peg rack: 20 in. W x 20 in. D
• Overall: 22¹¹⁄₁₆ in. W x 24 in. D (39⁹⁄₁₆ in. D when door is open) x 32⁵⁄₁₆ in. H
• 17.5 A, 2 kW, ⁴¹⁄₅₀ HP
• 120 V/60 Hz/3 ph
• 1³⁄₈-in.-diameter hole for 1-in. trade-size conduit
• ³⁄₄-in. female garden hosing fitting on 6-ft.-long hose supplied with unit

From The Manufacturer

Dishwasher, undercounter, 22-11/16"W x 24"D x 32-5/16"H, (24) racks/hr, low temperature chemical sanitizing, .92 gal/rack, delime cycle, service diagnostics with error notifications, soft start, chemical pumps, (1) chemical sensing indicator for sanitizer, 120v/60/1-ph, 17.5 amps, cULus, NSF

*Image may not depict product color, inclusions or accessories.

Specifications

Documents

• Spec Sheet
